EcoX: the AC series is availabe on the EcoX version, using natural refrigerants, Hydrocarbons R290.
Clean alert: advises with a blink when it’s time to clean the filter.
Electronic control: ambient and water temperatures may change throughout the years but your ice
machine will stay the same.
Front access condenser air filter: a do-it-yourself cleaning operation that saves time and money and
makes your ice maker live longer.
Individual transparent solid cube: each single cube is an artwork: crystal clear and perfectly shaped,
faithful to the Scotsman tradition.
Scale accumulation preventing system: traps ice makers’ enemy No. 1 in one place and makes it
harmless.
Ergonomic access to ice with sliding disappearing door: one-touch door lift, makes barman’s life
significantly easier.
Built-in storage bin: allows most undercounter installations for easier fit-in solutions.
EcoX: the AC series is availabe on the EcoX version, using natural refrigerants only, Hydrocarbons R290
or Carbon Dioxide R744.

AC 126 AC 176 AC 206 AC 226
Cube size: Cube size: Cube size: Cube size:
Small cube Small cube Small cube Small cube
Medium cube Medium cube Medium cube Medium cube
Large cube Large cube Large cube Large cube
Condensing system: Condensing system: Extra Large cube Condensing system:
Air cooled Air cooled Condensing system: Air cooled
Water cooled Water cooled Air cooled Water cooled
Max daily production: Max daily production: Water cooled Max daily production:
74 kg Medium cubes 85 kg Medium cubes Max daily production: 150 kg Medium cubes
137 kg Medium cubes

Storage bin capacity: Storage bin capacity: Storage bin capacity: Storage bin capacity:
39 kg 48 kg 50 kg 70 kg
Dimensions: Dimensions: Dimensions: Dimensions:
W 680 mm W 680 mm W 1250 mm W 1078 mm
D 600 mm D 600 mm D 622 mm D 715 mm
H 920 mm / 1010 mm with legs H 990 mm / 1080 mm with legs H 779 mm / 809 mm with legs H 1005 mm / 1085 mm with legs
