Cubic hot vitrines Reserves
General characteristics General characteristics
- Specially designed to hold, display and serve hot food presented on plates - Sliding doors on the service side of the display, to make easier product - Specifically designed to be installed under a worktop in order to hold · Automatic evaporation system of defrost water as an accessory.
or shallow GN 1/1 pans (e.g. hot appetizers, sandwiches, pies, pizza, etc.) loading/replacement operations. chilled or hot products. · Working temperatures: +0ºC/ +6ºC.
keeping displayed product at optimum temperatures during service time. - Closed service side: tempered front glass window, firmly fixed by using - Manufactured in stainless steel with a solid and robust structure. - Hot reserves:
- Structure manufactured in stainless steel with satin finish. anodized aluminum clamps which allows the glass to be folded for - Cold reserves: · Double-wall sliding doors and forced air heating system.
- 4mm thickness, very durable glass ceramic shelf and plate. cleaning. · With hinged doors or drawers, to house containers or grills GN 2/1 or · Working temperatures: +30ºC/ +90ºC.
- Heating system by hidden silicon heaters attached to the bottom of the - Robust structure with 13 mm thick overlap, once element is dropped-in on GN 1/1. - Electronic thermostat, with digital display, to control and regulate the
glass ceramic plate and shelf. the worktop, ensuring cleanness and aesthetics. · Forced draft evaporator and removable pull-out/push-in magnetic temperature at the desired set point.
- Foodshields with light and heat by protected halogen lamps located over - Working temperatures: +30ºC/ +100ºC in models with customer side door gasket, to keep maximum hygiene.
the glass ceramic plate and shelf (except with customer side closed). opened and +30ºC/+80ºC in models with customer side closed.
- Two (2) or three (3) electronic thermostats, with digital display, to control
and regulate the temperature on the glass ceramic plate and on the
shelf(ves) separately, at the desired set point.
DDRC4-21 DD DDRC5-22 HH TMH4-714 SE
MODEL GAS CODE DIMENSIONS CAPACITY GN Nº OF Nº OF POWER CLIMATE COLD €
(mm) DOORS DRAWERS (W) CLASS GROUP
DDHVC7-S-3-4 DDHVC7-W-3-4 DDHVC7-S-CL-2-4 COLD RESERVE
DDRC4-12 D R290 19105783 1370x676x450 GN 2/1 1 - 150 4 Included -
DDRC4-22 DD R290 19105784 1763x766x450 GN 2/1 2 - 210 4 Included -
DDRC5-12 D R290 19105785 1145x766x586 GN 2/1 1 - 165 4 Included -
CUT-OUT
MODEL VOLTAGE AND FREQUENCY CODE DIMENSIONS DIMENSIONS CAPACITY CLIENT SIDE POWER €
(HZ) (mm) (mm) GN 1/1 (W) DDRC5-22 DD R290 19105786 1763x766x586 GN 2/1 2 - 270 4 Included -
3 LEVELS SERVICE SIDE: SLIDING DOORS (S)
DDRC5-12 H R290 19105787 1145x766x586 GN 2/1 - 2 165 4 Included -
DDHVC7-S-3-3 220-240V 1N~ 50/60Hz 19106311 1115x720x952 1090x690 3 Open 3620 -
DDRC5-22 HH R290 19105788 1763x766x586 GN 2/1 - 4 270 4 Included -
DDHVC7-S-3-4 380-415V 3N~ 50/60Hz 19106312 1440x720x952 1415x690 4 Open 4970 -
DDRC4-21 DD R290 19105795 1370x676x450 GN 1/1 2 - 155 4 Included -
DDHVC7-S-3-5 380-415V 3N~ 50/60Hz 19106313 1765x720x952 1740x690 5 Open 6320 -
DDRC4-31 DDD R290 19105796 1763x676x450 GN 1/1 3 - 160 4 Included -
SERVICE SIDE: WALL TYPE (W)
DDRC5-21 DD R290 19105797 1370x676x586 GN 1/1 2 - 165 4 Included -
DDHVC7-W-3-3 220-240V 1N~ 50/60Hz 19106314 1115x720x952 1090x690 3 Open 3620 -
DDRC5-31 DDD R290 19105798 1763x676x586 GN 1/1 3 - 275 4 Included -
DDHVC7-W-3-4 380-415V 3N~ 50/60Hz 19106315 1440x720x952 1415x690 4 Open 4970 -
DDRC5-21 HH R290 19105799 1370x676x586 GN 1/1 - 4 165 4 Included -
DDHVC7-W-3-5 380-415V 3N~ 50/60Hz 19106316 1765x720x952 1740x690 5 Open 6320 -
DDRC5-31 HHH R290 19105800 1763x676x586 GN 1/1 - 6 275 4 Included -
2 LEVELS SERVICE SIDE: SLIDING DOORS (S) Check remote versions at the end of the chapter.
DDHVC7-S-CL-2-3 220-240V 1N~ 50/60Hz 19106317 1115x720x742 1090x690 3 Closed 1965 -
DDHVC7-S-CL-2-4 220-240V 1N~ 50/60Hz 19106318 1440x720x742 1415x690 4 Closed 2710 - MODEL CODE DIMENSIONS (mm) POWER €
(W)
DDHVC7-S-CL-2-5 220-240V 1N~ 50/60Hz 19106319 1765x720x742 1740x690 5 Closed 3465 - HOT RESERVE
TMH4-712 SE 19105725 1196x685x450 1450 -
TMH4-714 SE 19105726 1395x685x450 1450 -
TMH4-716 SE 19105727 1596x685x450 1450 -
TMH4-718 SE 19105728 1796x685x450 2470 -
TMH4-720 SE 19105729 1996x685x450 2470 -
TMH6-712 SE 19105730 1196x685x610 1450 -
TMH6-714 SE 19105731 1396x685x610 1450 -
TMH6-716 SE 19105732 1596x685x610 2470 -
TMH6-718 SE 19105733 1796x685x610 2470 -
TMH6-720 SE 19105734 1996x685x610 2870 -
COMMON ACCESORIES
KPSR 19056083 Set of 4 legs (height 150 mm) -
